3.2 Density

Why Refine the mesh?

Each element is connected to it’s surrounding elements. Edge elements have a boundary.

The data generated by a CFD analysis of a flow is discretized (link to intro part) so the resolution of the result will depend on the number of elements used to describe the space. This concept is well understood when applied to digital pictures.

A picture of a Rubix cube at 500 by 500 pixels reslution A picture of a Rubix cube at 100 by 100 pixels reslution A picture of a Rubix cube at 20 by 20 pixels reslution

3.3 Mesh Refinement
